If you own or want to build a biogas plant, you are making a valuable contribution to renewable energy production. But how do you ensure that your plant works reliably, delivers an optimum methane yield and always meets safety and environmental requirements? The answer lies in precise gas analysis. By closely monitoring the composition of your biogas at all times, you can control your plant more efficiently, avoid breakdowns and reduce your operating costs. At Fresenius Umwelttechnik, we understand how important accurate and continuous online gas analysis is to the success of your biogas plant. That’s why we offer you advanced gas measurement devices that have been specially developed for the requirements of biogas processes – for maximum process reliability, efficiency and longevity of your plant, as well as compliance with environmental standards and legal requirements.
Select a point on the graphic to find out information about the solutions for the respective gas tapping points below the graphic.
(The selection refers to the respective extraction point (eng. touchpoint) that would be suitable for your biogas plant)
After biogas upgrading, precise monitoring of the biomethane content (CH₄) and CO₂ content is crucial for product quality and the economic value of the gas. A high methane content and a low CO₂ content improve the combustion properties of the biomethane, increase energy efficiency and reduce emissions - which leads to a higher energy yield and thus better returns.
The GA 220 (Gas Analyzer 220) enables the continuous measurement of methane (CH₄) and carbon dioxide (CO₂) using the non-dispersive infrared (NDIR) measurement method. This method ensures precise and long-term stable measurements of the two gas components. The purer the biomethane - i.e. the higher the methane content and the lower the CO₂ content - the more efficient the combustion and the higher the value of the processed gas.
With the GA 220, you ensure that the upgraded biomethane achieves the required purity and that your plant operates both safely and efficiently. This not only maximizes the product quality, but also increases the efficiency of your biogas plant.
When feeding biomethane into the natural gas grid, precise monitoring of the methane concentration is crucial. After processing, methane concentrations of up to >99% by volume are expected at this point, which requires maximum accuracy.
The biomethane TDLAS measures methane (CH₄) with an accuracy of 0.01% by volume and overcomes the saturation effects that occur with conventional NDIR methods at high methane concentrations. Thanks to its laser-based technology, it detects specific absorption lines, making it ideal for measuring points with high concentrations.
Compact system solution: An equipment cabinet with the biomethane TDLAS allows precise methane measurements. If required, modules for monitoring other substances can be added.
When producing LNG (liquefied natural gas) and CNG (compressed natural gas), monitoring the gas composition is crucial. After processing, methane concentrations of up to >99% by volume are expected, while carbon dioxide (CO₂) and oxygen (O₂) must be kept within narrow limits to avoid crystallization (CO₂) and safety risks (O₂).
The biomethane TDLAS measures methane with an accuracy of 0.01% by volume and overcomes the limitations caused by saturation effects with NDIR in high methane concentrations. Modules with NDIR and electrochemical sensors can be added for monitoring CO₂ and O₂.
Efficient system solution
An appliance cabinet with the biomethane TDLAS and optional modules for CO₂ and O₂ measurement offers a precise and flexible solution. As the gas is already very pure, no additional gas coolers are required.
The gas extraction point directly after the fermentation process in the fermenter is an ideal point for monitoring the fermentation process. The resulting biogas is analyzed at this point in order to record key process parameters. The regular measurement of gas components such as methane (CH₄), carbon dioxide (CO₂), hydrogen sulphide (H₂S), oxygen (O₂) and hydrogen (H₂) provides valuable information about the condition and stability of the anaerobic fermentation. This allows deviations to be detected at an early stage and targeted measures for process optimization to be initiated.
The measurement of ammonia (NH₃) can also be integrated as an option. Recording the ammonia content provides additional insights into the microbial metabolism and the nutrient balance in the fermenter.
Other substances can also be monitored on request.
Our gas analyzers - such as the BioBasic - enable continuous online gas measurement directly in the process. With precise real-time data on the relevant gas components, you receive reliable monitoring that helps you to operate your biogas plant efficiently and safely.
Hydrogen sulphide (H₂S) is one of the most critical components in raw biogas, as it has a corrosive effect and can cause damage to downstream plant components - for example in upgrading to biomethane or in gas engines, which must comply with strict limits. In order to effectively reduce the sulphur content in biogas, precise monitoring both before and after desulphurization is crucial. It is important to know how high the H₂S concentration is before the gas is fed into the desulphurization process and to ensure that the desulphurization process achieves the desired effect.
Only with precise H₂S monitoring can you guarantee that the treated biogas can be safely reused - whether for upgrading to biomethane, in a combined heat and power plant (CHP ) or in other industrial applications. This ensures that all downstream processes are optimally protected and the specified limit values are adhered to.
Our gas analyzers - such as the BioBasic and the GAP 100 - monitor the H₂S content at the crucial points. You receive precise, real-time data that helps you to efficiently control the desulphurization process and avoid potential damage to downstream plant components. The devices offer reliable, continuous online measurement that can be seamlessly integrated into your processes.
Formaldehyde (CH₂O) can be produced under certain conditions after the combustion of biogas in a combined heat and power plant (CHP). This highly reactive and carcinogenic pollutant is subject to strict legal emission limits. In combined heat and power (CHP ) plants in particular, it is crucial to precisely monitor the formaldehyde concentration to ensure compliance with legal requirements and protection of the environment.
Our GA315 formaldehyde was specially developed for the measurement of hot gases that occur immediately after combustion in CHP units. The device uses the non-dispersive infrared (NDIR) measuring method to reliably detect formaldehyde even at high temperatures and in very low concentrations in the ppm range. This enables continuous measurement directly in the exhaust gas flow, ensuring seamless monitoring and documentation of the emission values.
The GA315 Formaldehyde offers a long-term stable and low-maintenance solution that directly supports test institutes and engine manufacturers in carrying out emission tests to comply with legal limits.
After biogas upgrading, precise monitoring of the biomethane content (CH₄) and CO₂ content is crucial for product quality and the economic value of the gas. A high methane content and a low CO₂ content improve the combustion properties of the biomethane, increase energy efficiency and reduce emissions - which leads to a higher energy yield and thus better returns.
The GA 220 (Gas Analyzer 220) enables the continuous measurement of methane (CH₄) and carbon dioxide (CO₂) using the non-dispersive infrared (NDIR) measurement method. This method ensures precise and long-term stable measurements of the two gas components. The purer the biomethane - i.e. the higher the methane content and the lower the CO₂ content - the more efficient the combustion and the higher the value of the processed gas.
With the GA 220, you ensure that the upgraded biomethane achieves the required purity and that your plant operates both safely and efficiently. This not only maximizes the product quality, but also increases the efficiency of your biogas plant.
When feeding biomethane into the natural gas grid, precise monitoring of the methane concentration is crucial. After processing, methane concentrations of up to >99% by volume are expected at this point, which requires maximum accuracy.
The biomethane TDLAS measures methane (CH₄) with an accuracy of 0.01% by volume and overcomes the saturation effects that occur with conventional NDIR methods at high methane concentrations. Thanks to its laser-based technology, it detects specific absorption lines, making it ideal for measuring points with high concentrations.
Compact system solution: An equipment cabinet with the biomethane TDLAS allows precise methane measurements. If required, modules for monitoring other substances can be added.
When producing LNG (liquefied natural gas) and CNG (compressed natural gas), monitoring the gas composition is crucial. After processing, methane concentrations of up to >99% by volume are expected, while carbon dioxide (CO₂) and oxygen (O₂) must be kept within narrow limits to avoid crystallization (CO₂) and safety risks (O₂).
The biomethane TDLAS measures methane with an accuracy of 0.01% by volume and overcomes the limitations caused by saturation effects with NDIR in high methane concentrations. Modules with NDIR and electrochemical sensors can be added for monitoring CO₂ and O₂.
Efficient system solution
An appliance cabinet with the biomethane TDLAS and optional modules for CO₂ and O₂ measurement offers a precise and flexible solution. As the gas is already very pure, no additional gas coolers are required.
The gas extraction point directly after the fermentation process in the fermenter is an ideal point for monitoring the fermentation process. The resulting biogas is analyzed at this point in order to record key process parameters. The regular measurement of gas components such as methane (CH₄), carbon dioxide (CO₂), hydrogen sulphide (H₂S), oxygen (O₂) and hydrogen (H₂) provides valuable information about the condition and stability of the anaerobic fermentation. This allows deviations to be detected at an early stage and targeted measures for process optimization to be initiated.
The measurement of ammonia (NH₃) can also be integrated as an option. Recording the ammonia content provides additional insights into the microbial metabolism and the nutrient balance in the fermenter.
Other substances can also be monitored on request.
Our gas analyzers - such as the BioBasic - enable continuous online gas measurement directly in the process. With precise real-time data on the relevant gas components, you receive reliable monitoring that helps you to operate your biogas plant efficiently and safely.
Hydrogen sulphide (H₂S) is one of the most critical components in raw biogas, as it has a corrosive effect and can cause damage to downstream plant components - for example in upgrading to biomethane or in gas engines, which must comply with strict limits. In order to effectively reduce the sulphur content in biogas, precise monitoring both before and after desulphurization is crucial. It is important to know how high the H₂S concentration is before the gas is fed into the desulphurization process and to ensure that the desulphurization process achieves the desired effect.
Only with precise H₂S monitoring can you guarantee that the treated biogas can be safely reused - whether for upgrading to biomethane, in a combined heat and power plant (CHP ) or in other industrial applications. This ensures that all downstream processes are optimally protected and the specified limit values are adhered to.
Our gas analyzers - such as the BioBasic and the GAP 100 - monitor the H₂S content at the crucial points. You receive precise, real-time data that helps you to efficiently control the desulphurization process and avoid potential damage to downstream plant components. The devices offer reliable, continuous online measurement that can be seamlessly integrated into your processes.
Formaldehyde (CH₂O) can be produced under certain conditions after the combustion of biogas in a combined heat and power plant (CHP). This highly reactive and carcinogenic pollutant is subject to strict legal emission limits. In combined heat and power (CHP ) plants in particular, it is crucial to precisely monitor the formaldehyde concentration to ensure compliance with legal requirements and protection of the environment.
Our GA315 formaldehyde was specially developed for the measurement of hot gases that occur immediately after combustion in CHP units. The device uses the non-dispersive infrared (NDIR) measuring method to reliably detect formaldehyde even at high temperatures and in very low concentrations in the ppm range. This enables continuous measurement directly in the exhaust gas flow, ensuring seamless monitoring and documentation of the emission values.
The GA315 Formaldehyde offers a long-term stable and low-maintenance solution that directly supports test institutes and engine manufacturers in carrying out emission tests to comply with legal limits.
For
The power pack with up to 5 measuring points.
For
The power pack with up to 5 measuring points.
For
Strict formaldehyde monitoring with low detection limits
Hot gas measuring device for compliance with strict emission limits.
For
Slide-in system without running costs.
For
The fastest and most precise continuous online measurement, at high concentrations without saturation effects with an accuracy of 0.01% vol.
For
The fastest and most precise continuous online measurement, at high concentrations without saturation effects with an accuracy of 0.01% vol.
Our gas coolers are essential components of sample gas conditioning and are used to significantly reduce moisture in gas samples. They ensure stable and reproducible measurement results by preventing condensation in sensitive measuring cells.
The SmartControl 300 is a cost-effective stationary NDIR measuring device developed for monitoring threshold concentrations in gas mixtures containing solvents. It is characterized by high long-term stability and low operating costs.
The ExGard is an explosion-proof gas detector specially developed for monitoring toxic and flammable gases such as methane (CH₄), carbon monoxide (CO) and oxygen (O₂). It works in critical industrial environments and ensures maximum safety.
The Gas Analyzer Portable 100 (GAP 100) is a flexible, portable gas measurement system designed for field use. With the ability to precisely measure gases such as CH₄, CO₂, H₂S and O₂, the device is ideal for mobile spot measurements in biogas, sewage treatment and landfill plants.
Our gas coolers are essential components of sample gas conditioning and are used to significantly reduce moisture in gas samples. They ensure stable and reproducible measurement results by preventing condensation in sensitive measuring cells.
The SmartControl 300 is a cost-effective stationary NDIR measuring device developed for monitoring threshold concentrations in gas mixtures containing solvents. It is characterized by high long-term stability and low operating costs.
The ExGard is an explosion-proof gas detector specially developed for monitoring toxic and flammable gases such as methane (CH₄), carbon monoxide (CO) and oxygen (O₂). It works in critical industrial environments and ensures maximum safety.
The Gas Analyzer Portable 100 (GAP 100) is a flexible, portable gas measurement system designed for field use. With the ability to precisely measure gases such as CH₄, CO₂, H₂S and O₂, the device is ideal for mobile spot measurements in biogas, sewage treatment and landfill plants.
Our gas coolers are essential components of sample gas conditioning and are used to significantly reduce moisture in gas samples. They ensure stable and reproducible measurement results by preventing condensation in sensitive measuring cells.
The SmartControl 300 is a cost-effective stationary NDIR measuring device developed for monitoring threshold concentrations in gas mixtures containing solvents. It is characterized by high long-term stability and low operating costs.
Every system has its own requirements – and we deliver the right solution. Whether compact system cabinets, customized integration into existing infrastructures or completely individual concepts: We develop solutions that are precisely tailored to your needs.
Our approach makes it possible to optimally combine high-performance gas analyzers and other process measurement technologies – whether in a centrally organized housing or through flexible integration directly into your existing system. You not only save space, but also benefit from a well thought-out structure that makes maintenance and operation easier.
These engineering services are complemented by our comprehensive service concept. If required, the components can be easily removed and sent in for maintenance – alternatively, our experienced service team is available to support you directly on site. This maintenance model guarantees minimal downtime and ensures the continuous operation of your system.
Our gas analyzers ensure continuous and precise monitoring of your biogas production so that you are always in control of the process. Reduce the risks to your plant, protect your plant from premature wear and tear, ensure the quality of your production and monitor emissions in an environmentally conscious way to comply with regulations and ensure employee safety.
Thanks to our high-precision gas analyzers, you can monitor the methane content in real time. This allows you to ensure that the minimum quality for feeding into the natural gas grid is achieved – a prerequisite for generating additional revenue. A higher methane yield means greater efficiency and higher profits, as you get more valuable biomethane out of your plant.
With accurate H₂S measurement, you can protect your gas engines and catalytic converters from harmful corrosion. This not only reduces maintenance costs, but also significantly extends the service life of your system technology. With our gas analysis devices, you can minimize expensive repairs and unnecessary downtime.
Our appliances are designed for a long service life and minimal maintenance. This reduces the running costs of your system. Should maintenance nevertheless be necessary, we offer you rental devices so that your system can continue to operate without interruption. Investments in our measurement technology pay off quickly – through optimized processes, reduced operating costs and higher yields.
With our on-site service and the option to easily send in devices for maintenance, you can always be sure that your biogas plant is running smoothly. Our service team is at your side so that you can concentrate on the essentials: efficient and economical production.
